Overview
Three-phase energy meter for indirect metering via transformers
IONT meter is a metering module for PREMIUM versions of charging stations, intended for industrial and commercial installations. It meters electricity consumed during EV charging indirectly via external 5/100 to 5/300 A current transformers. MID certification makes it suitable for billing purposes.
Key features
Indirect metering
Three-phase metering via external current transformers, suited to high currents and large supply points.
Choice of transformers
The current range is set by the selected 5/100, 5/150, 5/200, 5/250 or 5/300 A transformers, chosen to match the installation's power.
Required accessories
The meter requires three current transformers, sold separately.
MID certified
Metering is intended for billing purposes.
Technical specifications
| Metering type | indirect, external current transformers |
|---|---|
| Phases | 3 |
| Current range | depends on the selected transformers, 5/100 to 5/300 A |
| Transformers required | 3 pcs, sold separately |
| Certification | MID, billing-grade metering |
| Intended for | PREMIUM versions of charging stations, industrial and commercial applications |
Metering for billing
Contact us for help with choosing transformers to match the installation's power. Product documentation is available for download.
